Greinacher Circuit Voltage Doublers

I used a 3.3 µF, 370VAC capacitor in a previous Villard Circuit voltage doubler, but I used 67 nF capacitors in a Greinacher Circuit voltage doubler.

That’s a huge capacitance difference. Did I do the Greinacher Circuit correctly?

Since I did the Villard and Greinacher voltage doublers, my experimentation took a sad turn. I tried polarized electrolytic capacitors in a Villard circuit. Apparently the electrolyte solution boiled. The capacitor burst. Loud bang.

I tried some non-polarized, ceramic disk capacitors, but something went wrong, and the 1N4001 diode in the Villard circuit smoked. Somehow this shorted my doorbell transformer. It quit working.

I got a new doorbell transformer, then smoked a tantalum capacitor.

I finally bought some metallized Polypropylene film 400V capacitors, and some FR207 diodes, which have a 2A forward current capacity.

Doorbell Transformer

I bought an Eplzon brand transformer. According to my multimeter, the 120V side has a resistance of 18.5 Ω. The (nominal) 24V side has a resistance of 1.0 Ω The multimeter consistently measures the stepped down output, which is nominally 24V, at 27.4 VAC.

Eplzon doorbell transformer output

Peak-to-trough says 7.6V, but the oscilloscope probe was set to 10x attenuation, so it’s actually 76V. Now that I think about it, is the FR207 diode’s 40V reverse voltage rating good enough? They didn’t even get warm while I was fiddling.

Greinacher Circuit

Greinacher circuit schematic

I used 0.56 μF (rated) capacitors, and FR207 diodes. The breadboard looked like this:

Greinacher circuit breadboard

AC comes in from the left on gray wires. DC is on the right, the top orange wire is positive, the bottom, negative.

The output waveform was very boring: a straight line at 74VDC. This is different than my previous Greinacher circuit, which had 67 nF capacitors, and showed a lot of ripple.

I unplugged the doorbell transformer, but left the oscilloscope on. The straight line gradually decayed from 74V to 0V. I think this is the capacitors discharging through the doorbell transformer and oscilloscope resistance.

I tried other capacitance values. 0.22 μF capacitors produced exactly the same flat 74V.

0.047 μF capacitors gave the DC output a lot of ripple.

Greinacher circuit small capacitor ripple

This is my whole setup, doorbell transformer on left to oscilloscope on right.

Greinacher circuit test set up
